Magnetic lock 1500 LBS

Magnetic Lock 1500 LBS with the door status signal output led indicate and timer,specially used to normal glass door, wooden door,metal door,fire doors,and all kinds of door.Hoisting design,saves time and power when installation.Inward door,frame-less glass door,narrow door all have a complete set of accessories.Special Anti-residual magnetic design makes automatic access control safer.

Hold force 1500 LBS options are in single and double door models.

SPECIFICATION
Voltage	12V/24VDC (Selectable)
Current Draw	600mA/12V , 300mA /24V
Holding Force	about 1500LBS
Built-in voltage spike suppressor ,With Bi-color LED
Special Finish : Zinc (on the magnet & armature plate)
Anodized aluminum housing
Adjustable mounting plate for easy and appropriate installation
