RD02001 - AUTO SLIDING MAG LOCK

Radiant auto slide door magnetic lock has been specifically designed for automatic sliding door applications where the size of common locking mechanisms create installation difficulties.. Hoisting design,saves time and power when installation. Complete set of accessories available for auto slide lock. Special Anti-residual magnetic design makes automatic access control safer and more convenient.

Model

RD02001 : Magnetic Lock for Auto-sliding Door

SPECIFICATION
Voltage	AC110V / AC220V
Current Draw	50mA/AC110V, 25mA/AC220V
Holding Force	about 80KG / 175LBS
Input Signal	Remote control, digital keypad, proximity card reader, push button, or any electronic access device.
Output Signal	Signal will trigger NO type relay which will in turn activate motor to open sliding door.
With lock sensor
