RD01600M - MORTICE MOUNTED 600 LBS MAG LOCK

Magnetic Lock 600 LBS with the door status signal output led indicate and timer,specially used to normal glass door, wooden door,metal door,fire doors,and all kinds of door. Hoisting design,saves time and power when installation.Inward door,frame-less glass door,narrow door all have a complete set of accessories. Special Anti-residual magnetic design makes automatic access control safer.Suitable for sliding doors.

Hold force 600 LBS options are in single and double door models.

SPECIFICATION
Voltage	12V/24V (Selectable)
Current Draw	500mA/12V , 250mA /24V
Holding Force	about 600LBS
Built-in voltage spike suppressor
Anodized aluminum housing
Special Finish	Zinc (on the magnet & armature plate )
