RD14203 - Fail Safe Electric Bolt

Electric Bolts provide electrical locking of a door by driving bolt into the strike preventing the door from opening. They are a comparatively simple means of locking a door electronically, and provide a great level of security with low level power usage.

� Suitable for double swing door

� With lock and Door status sensor

� Built-in voltage spike suppressor

� Use jumper to select auto-lock time delay (0, 2.5, 6 sec.)

� Round plate type: easy to make appropriate installation holes

SPECIFICATION
Fail-safe	Locked when energized
Face plate Material	Aluminium
Cover plate	Stainless Steel
Weight	0.9KGS
Voltage	12VDC
Current Draw	Puli-in : 1A / 12VDC
Holding	0.3A / 12VDC
