RD14201 - Fail Safe Electric Bolt

Electric Bolts provide electrical locking of a door by driving bolt into the strike preventing the door from opening. They are a comparatively simple means of locking a door electronically, and provide a great level of security with low level power usage.

� Suitable for double swing door

� Intelligent Auto-Relock

� With lock and Door status sensor

� Built-in voltage spike suppressor

� Use jumper to select auto-lock time delay (0, 2.5, 5 sec.)

� Round plate type: easy to make appropriate installation holes

SPECIFICATION
Request to EXIT	The lock has 2 wires for remote release
Fail-safe	Locked when energized
Face plate	Aluminium
Cover plate	Stainless steel
Weight	0.9KG
Voltage	12VDC or 24VDC
Current	0.9A / 12VDC , 0.5A/24VDC
Standby	0.2A / 12VDC , 0.1A/24VDC
